Product Description
|
Technical Data M-tex 30 |
Sternmed Digital Mammography System |
|
|
Main unit |
|
|
|
Size |
1110 (L) x650 (W) x2050 (H) mm |
|
|
Weight |
< 320Kg |
|
|
C-arm rotating range |
650~1400mm |
|
|
C-arm rotating angle |
+185° |
|
|
SID |
66CM |
|
|
Dual-function pedals |
2 pay |
|
|
Patient protective mask |
Removable |
|
|
C-arm rotation angle, position, oppressive force, oppression thickness be displayed digitally |
C-arm, two displays on the column |
|
|
Lifting range for compression plate |
0-270mm (pressure plate to oppression platform height)(manual, electric) |
|
|
Compression plate |
Conventional compression plate: 24cm x 30cm |
|
|
Conventional compression plate: 18 cm x 24 cm |
||
|
9cm conventional point compression plate 9cm x 9cm |
||
|
Enlarge oppression plate 18cm x 24cm |
||
|
Enlarged compression plate 9cm x 9cm |
||
|
Auxiliary compression plate |
||
|
Small breasts oppression plate |
||
|
Amplification system |
1.8X magnification platform 1.5X magnification platform |
|
|
Cabinet |
||
|
Column dimensions (length X width X height) |
282mmx633mmx830mm |
|
|
Weight |
≤50Kg |
|
|
Console (Optional) |
||
|
Column dimensions (length X width X height) |
784mmX411.5mmX1071mm |
|
|
Weight |
≤30Kg |
|
|
Tube: IAE |
||
|
Ingredient |
Molybdenum Target |
|
|
Tube voltage range |
20~40kV |
|
|
Focus |
0.1/0.3mm |
|
|
Power |
4.9kW |
|
|
Anode rate |
3000/10000rpm(Low / High） |
|
|
Maximum anode dissipation rate |
750W |
|
|
Heat capacity |
225kJ（300kHU） |
|
|
Pipe sleeve of thermal capacity |
320kJ |
|
|
Tube sets of maximum cooling rate |
210W |
|
|
Inherent filtration |
0.5mm Be |
|
|
Angle |
10°/16° |
|
|
Length |
320mm |
|
|
Maximum diameter |
140mm |
|
|
Weight |
15kg |
|
|
Cooling |
Nature / air |
|
|
|
||
|
High Voltage Generator: Spellman |
||
|
Line Power 1 |
220V±20VAC, single phase, 50/60Hz |
|
|
Line Power 2 |
380V±38VAC, three phase, 50/60Hz |
|
|
Photography voltage |
20-40KV (step 0.5KV) |
|
|
Photography current |
10-160mA (sub-file adjustment) |
|
|
Maximum power shooting conditions (@ 0.1S) |
125 mA @ 40 kVp |
|
|
Nominal power |
5kW |
|
|
Photography Time |
5ms-5s |
|
|
Operating Frequency |
25kHz |
|
|
Maximum KV |
40KV |
|
|
mAs Range (mAs) |
0.5mAS-500mAS |
|
|
Control grids |
There are (vibration grids) |
|
|
AEC |
There are (automatic AEC, semiautomatic AEC) |
|
|
Collimator: Ralco |
||
|
Maximum X-ray region |
24X30cm（SID=66cm） |
|
|
Light time |
<15 s |
|
|
Average illuminance |
≥160LUX |
|
|
Filtration |
0.03mmMo,0.025mmRh |
|
|
Adjustment method |
Automatic |
|
|
Power supply |
24V DC, 2A |
|
|
Weight |
3.6Kg |
|
|
Size |
240 X175 X82MM |
|
|
The shape of the light field |
≤24X30cm (supports continuous adjustment) |
|
|
HV Cable: |
||
|
Power |
60kVDC |
|
|
DC voltage |
90kVDC/15min |
|
|
AC voltage |
70kV/5min |
|
|
Length |
10m |
|
|
FPD Detector: Anrad |
||
|
Conversion Screen Type |
Amorphous selenium |
|
|
Effective pixel region |
24cmХ30cm |
|
|
Pixel matrix |
2816X3584 |
|
|
Pixel size |
85um |
|
|
Spatial resolution limit |
8lp/mm |
|
|
Energy range |
20～40kVp |
|
|
A / D converter |
16-bits |
|
|
Acquisition cycle |
8s (including image processing time was 10s) |
|
|
Data transfer mode |
Gigabit network transmission |
|
|
Weight |
3kg |
|
|
Computer System |
||
|
Monitor |
LCD monitors, 19 inch, 1M color |
|
|
Size |
440mm*175mm*413mm |
|
|
Volume |
25L |
|
|
Weight |
8.5 kg |
|
|
Chipset |
INTER Q77 |
|
|
Processor |
I5-3470 (VPRO) (CORE I5 3.2G 6M cache) |
|
|
Integrated graphics |
Integrated graphics |
|
|
Sound Card |
Integrated High Definition Audio |
|
|
NIC |
Motherboard integrated Gigabit Ethernet |
|
|
Independent card |
PRO/1000 PT Desktop Adapter |
|
|
Memory Specifications |
DDR3 1333 |
|
|
Memory |
8G DDR3 |
|
|
Hard Specifications |
SATA 7.2K |
|
|
Hard drive capacity |
500G hard disk partitions: C disk 60GB NTFS format, E disk 20GB FAT32 format, the remaining space forthe D drive NTFS format |
|
|
COM interface |
COM1 |
|
|
Drive bays |
Interior: 2 * 5.25 1 * 3.5 external: 1 * 3.5 (expandable to 2 * 3.5) |
|
|
Expansion Slots |
2*PCI 2.3 1*PCIeX1 1*PCIeX16 |
|
|
Software |
||
|
Patient Management |
patient information registration, save, set an appointment, query and other functions |
|
|
Inspection management |
parameter setting, exposure collection, automatic image processing |
|
|
Image Browser |
image selection, image processing (crop, zoom, grayscale adjustment, rotate, flip, tag, window layout, etc.) |
|
|
Image post-processing |
image enhancement, tissue equalization, noise reduction, gradation values of tensile |
|
|
Image output |
support for laser printer output, support for the laser camera output, DICOM interface and hard |
|
|
Data Management |
data deletion, statistics, edit, backup and recovery |
|
|
Other features |
detector calibration procedures, failure error function, Work list module |
|
|
Packing Information |
||
|
packing size （mm)(L*W*H) |
Weight 320 KG |
|
|
Column : 2230*1060*1480 |
60 |
|
|
Cabinet: 800*490*1035 |
20 |
|
|
Accessories :1080*635*730 |
30 |
|
|
Compressing devices: 1080*635*730 |
30 |
|
|
Environment requirement |
||
|
Work Environment |
Temp：12°C～37°C |
|
|
Humidity ：20%～90% (No condensation) |
||
|
Atmospheric pressure ：70kPa～106kPa |
||
|
Storage Environment |
Temp：5°C～40°C |
|
|
Humidity ：20%～90% |
||
|
Atmospheric pressure：70kPa～106kPa |
||
